Steico - Steico Universal album

Finishing panel with a wide range of applications made of wood fiber for roof, wall and floor constructions.

Special advantages

• high compressive strength
• laid directly on the rafters
• excellent insulating properties
• thermal bridge reduction
• openly diffused
• rain protection for the roof structure in a slope? 20o (special cutter)
• up to four weeks as a temporary roof
• effective protection against wind, dust, moisture and noise
• regulates the microclimate in the room
• ecological and environmentally friendly
• are recyclable

Material

Insulation board manufactured in accordance with PN EN 13171 and PN EN 13986 with continuous quality control.

Storage and transport

• lying down, flat in a dry place
• edges must be protected against damage
• Remove the plastic packaging only when the pallet is on a stable, level surface

Technical data

• production and control according to PN EN 13171 and PN EN 13986,
• plate designation: WF - EN 13171 - T4 - DS (70, -) 2 - CS (10 Y) 100 - TR30 - WS1,0 - AF100; EN 622-4 - SB.H - E1,
• edges: pi profile and groove,
• fire classification according to PN EN 13501-1: E,
• sd value [m]: 0.11,
• water absorption with short-lasting immersion [kg / m2]: ≤1.0,
• compressive stress at 10% relative strain s10 [N / mm2]: 0.20,
• tensile strength perpendicular to the face ^ [kPa]: ≥30,
• raw materials - natural: wood fiber, aluminum sulfate, paraffin, water glass, hydrophobizing agents, layer gluing,
• raw materials - bituminated: wood, bitumen, aluminum sulphate, paraffin, hydrophobizing agents,
• waste code: 170604,
