Darco - system of connections to fireplaces and solid fuel boilers SPK - black high bend

A high bent elbow with a revision and a 90 damper, is used to build chimney connections (flue in). The chimney connection system can be used as a connection to fumes discharge boilers, the temperature of which can reach 1000 C. Recommended for fumes from the fireplace and solid fuel heating devices operating without condensation.

The chimney connection system is used for the construction of chimney connections, made entirely of DC01 grade black steel. Recommended for the removal of exhaust gases from the fireplace and solid fuel heating devices operating without condensation. This system can be used as a connection to fumes discharging boilers, the temperature of which can briefly reach 1000 * C. System components do not constitute an independent chimney.

• Maximum continuous working temperature: 600 * C
• Material: DC01 2mm sheet, painted with Senotherm heat-resistant paint
• Warranty: 2 years

The connections of the element should be sealed with a special silicone compound - resistant up to a temperature of 1200 * C

Benefits

• very easy and quick assembly
• high durability
• available in black (standard) and graphite (on request)

Application

• for the construction of chimney connections with a fireplace or a solid fuel stove
